3KV Compact Polymer Housing Lightning Surge Arrester for Power Transformers / Distributors Protection
Description:
The lighting arrestor is the most advanced over-voltage protector. It is widely used as protective
devices against switching and lightning over voltages in power electrical systems such as power transformers, distributors,generators, compensation capacitors. Its core component--resistance slice adopts the material including zinc oxide and many kinds of metal oxides, compared with traditional silicon-carbide arrester, its volt-ampere characteristic of resistance slice has been improved to great degree, as well as the current-transmit ability of resistance slice, as a result, the capability of arrester has been improved basically and thoroughly.
Features:
1. Compact and Lightweight
2. Extremely Safe Pressure Relief Performance
3. Superior Performance against Environmental Contamination
4. Directly Molded Structure
5. Compliance with International Standards(IEC60099-4)
6. Simple Support Structure
7. Manufactured at Advanced ISO-9001 certified facilities
Applications:
1. Distribution networks
2. Transmission line
3. Substation
4. Railway power station
5. Alternator and electromotor
Specifications:
1. Lightning arresters 10kA/Surge arrestors 3kV/China manufacture/more than 20years experience
2. Since 1993years
| Type | YH10W5-3/8.1 | 4/10µS High current impulse kA | 100 |
| Rated voltage---------kV | 3 | Lightning impulse withstand kV | 60 |
| MOCV ----------------kV | 2.55 | Power frequency voltage withstand(dry/wet)kV | 10 |
| Nominal Current-------kV | 10 | 0.1S TOV--------------kV | 3.6 |
| Residual voltage of steep impulse----at 5kA(kV) | 9.2 | 1S TOV----------------kV | 3.45 |
| 8/20µS Residual voltage of lightning impulse current kV(Peak value)-----at 5kA(kV) | 8.5 | 10S TOV---------------kV | 3.3 |
| Residual voltage of switching impulse current kV (peak value)----at 1kA (kV) | 6.3 | 1200S TOV-------------kV | 3 |
| 1mA D.C reference voltage (kV) | 4.24 | Creepage distance ----mm | 272 |
| Line discharge level | 1 | Material employed in series non-linear resistor | Zinc Oxide |
| 2mS long duration impulse current A | 400 | Material of housing | silicon rubber |
